Product Category: | Sewage treatment device |
Brand Name: | SSME |
Country of Origin: | China/Malaysia |
Model Number: | 10 people, 15 people, 20 people, 25 people, 30 people, 40 people, 50 people, 60 people, 80 people, 100 people, 150 people, 200 people, 250 people, 300 people, 400 people |
Function: | Treat the domestic sewage on board ships to make the discharged water meet the IMO MEPC.227(64) resolution |
Standard: | IMO MEPC.227(64) CCS/MED |
Application: | It is widely applied in ships, port terminals, anchorages and water service areas. |
Printing | Customized Printing, OEM services |
Principle: This device and treatment process comprehensively apply electrocoagulation technology, biological treatment technology, membrane separation technology and physical separation technology. By rationally arranging the treatment process and strengthening the combination of coagulation and biochemical treatment, it overcomes the inherent shortcomings of the existing membrane bioreactor (MBR), and achieves breakthroughs in stabilizing nitrogen and phosphorus removal effects, enhancing sludge activity and preventing membrane fouling
Rated number of users: 10 people, 15 people, 20 people, 25 people, 30 people, 40 people, 50 people, 60 people, 80 people, 100 people, 150 people, 200 people, 250 people, 300 people, 400 people
Electric power supply: AC220V 60Hz, AC380V 50Hz, AC440V 60Hz
Discharge pressure: The emergency discharge pressure is 0.08MPa, and the qualified water discharge pressure is 0.1MPa
Emission standards: TSS no more than 35mg/L, BOD5 no more than 25mg/L, COD no more than 125mg/L, coliform count no more than 100 per 100 mL, PH: 6-8.5, residual chlorine (Cl-) < 0.5 mg/l
Others: Ambient temperature: 0℃-50℃, toilet flushing water temperature: 5℃-30℃, fresh water, relative humidity: ≤95%
Applications
It is widely applied in ships, port terminals, anchorages and water service areas.
Certification
CCS、DNV.GL、BV
Competitive Advantage
1. This device uses metal hydroxyl complexes produced by ionization as wastewater flocculants and combines aerobic and anaerobic biological reactions as well as membrane separation technology. It has extremely strong deoxygenation and phosphorus removal effects.
2. This device utilizes the effect of electromagnetic fields to promote the growth of microorganisms in sludge, stimulate the benign metabolism of the bacterial community, and effectively enhance the somatic activity of sludge bacteria.
3. This device effectively prevents membrane fouling by transforming pollutants and suspended solids in sewage from a freely distributed state to an aggregated state, thereby suppressing and avoiding the adhesion and penetration of pollutants.
4. This device rationally arranges and plans the sequence of contact oxidation, anaerobic sedimentation, membrane biological reaction and electrocoagulation on the main line of the treatment process, and has an ideal treatment process and technological structure.
5. This device uses the electrocoagulation electrode as the sacrificial anode to effectively prevent and delay the corrosion damage of the device body and components, significantly extending its service life.
6. This device does not add any chemical agents during the sewage treatment process, generates a small amount of sludge, and causes no secondary pollution. It is an environmentally friendly pollutant removal technology and equipment.
Customer case study
The products are sold far and wide to Southeast Asia, Europe, the Middle East, Latin America and other regions, and have received high praise from customers.
