Air Compressor

Air enters the air filter through a telescopic hose and is first sent to the first-stage cylinder for the first compression. It then flows through the first-stage exhaust pipeline equipped with a first-stage safety valve into the second-stage cylinder for the second compression. After that, the air passes through the second-stage exhaust pipeline into an oil-water separator fitted with a second-stage safety valve, where oil, water, and gas are separated. Subsequently, it enters the third-stage cylinder for the final compression. Finally, the discharged high-pressure gas undergoes purification treatment via a filter equipped with a final safety valve, and then the pure high-pressure gas is delivered into the user’s gas storage cylinder through an inflation nozzle with a pressure retaining valve.
All key components are manufactured using high-precision CNC machining centers, and the entire equipment is installed and tested in strict compliance with the compressor standards of developed countries in Europe and America.

Availability:

Quantity:



Inquire Add to Basket

Product Description

Place of Origin:	Malaysia/China
Brand Name:	SSME
Certification:	Complies with EN12021 Standard
Model Number:	SSME-XF-05(MCH/6;MCH/13;MCH/16)
Discharge of the pump:	100 L/min (6 m³/h)
Size:	700380420mm
Working Pressure:	225bar/330bar
Accessories:	Oil; filter; inflation port
Printing	customerized Printing, OEM services

The air inflator pump is a machine that compresses air step-by-step to a high pressure; it functions to increase gas pressure or transport gas. It can compress air in its free state to highly compressed air with a gauge pressure of 225bar/330bar. Subsequently, the air passes through the liquid-gas separator of the compressor component to remove water, oil, and impurities. The separated high-pressure air then goes through an air filtration system containing activated carbon to eliminate odors from the high-pressure air, thereby purifying the high-pressure air. The entire process involves gradually compressing the air to 225bar/330bar, after which the pure high-pressure air is injected into a gas storage cylinder via an air hose.he device also has 200L/300L

Medium: Breathable： Air
Breathing Air Quality: Complies with EN12021 Standard
Discharge of the pump: 100 L/min (6 m³/h)
Working Pressure: 225bar/330bar
Noise Level: 95 dB; 97 dB
Power Source: Single-phase Motor; Three-phase Motor; Gasoline Engine
Power: 2.2KW; 2.2KW; 4.2KW
Dimensions: 700*380*420mm
Weight: 46 kg; 44 kg

Applications

It is widely used in various industries such as diving, fire protection, chemical engineering, oil fields, medicine, military, shipping, aerospace, sports shooting, and special-purpose vehicles.

Certification

It complies with the technical requirements of GB/T 31975-2015 Compressed Air for Respiratory Protection.

Competitive Advantage

The drive methods include 220V/380V motors and gasoline engines for option. Meanwhile, we also provide high-pressure air inflator pumps with capacities of 215L and 300L.

Customer case study

The products are exported to shipowners and shipyards in South Korea, Southeast Asia, Europe, the Middle East, and other regions, and have received high praise from customers.
